AIS 140 GPS device Product Specifications
ADD Technologies (India) Limited is an advanced technology enterprise that provides the state-of-the-art GPS fleet tracking solutions and devices that are designed according to the specifications of the Ministry of Road Transport & Highways (MORTH), GOI and enables tracking, monitoring and optimizing your fleet with end to end solutions deployed across various devices.
What does AIS 140 mean?
Automotive Industry Standard-140 or AIS-140 is the Intelligent Transport System (ITS) that the government of India have designed to optimize and secure the efficiency of the transport system in India. This design has been proven worldwide to enhance the use of the present transport foundation up to its optimum ability which helps to improve the transport system in its efficacy, value, safety and security. The implementation of AIS 140 is being done all over the country.
Who should use the AIS 140 GPS Tracker?
AIS140 is the latest inclusion in the automotive industry standards in the Intelligent Transport System (ITS). ITS have become a prerequisite today, as with the growing number of vehicles everyday there should be more stringent regulations by the government that addresses crisis and safety standards which has to be followed by all the transport systems especially the public transport system i.e., roadways, railways, airways and waterways and be tagged with the AIS 140 GPS tracking devices. Emergency Button and Vehicle Location Tracking are the two AIS-140 necessities in a GPS device.
The GPS devices of RelyEon are all ICAT tested and also AIS 140 approved that has added value with another level of commitment towards our customers. GPS devices have been declared mandatory since April 2019 for all public passenger vehicles, thus providing you another motive to enhance your business’s reliability, safety and growth.
Our GPS devices are ICAT certified and AIS 140 approved. The devices are designed to track and monitor vehicles through the GPS Monitoring systems, that will allow fleet managers to swiftly redistribute the complete collection of solutions within no time.
Add Tech’s advanced solutions offer, geo-fencing, vehicle immobilization, over-speed alarm, theft-alert and even ignition on/off alert which can be valuable in domains such as school and employee transportation, intelligent transport systems in smart cities, Mining, Oil and Gas, Logistics and Transportation.
AIS 140 Business Enquiry
Buses
Both Private and State owned Inter and Intra City buses
Cabs
- Car & Bus Cab Fleet owners
- Rental Cab Operators
- Cab Hiring Service providers
- Self driven Vehicle Hiring operators
Establishments
- Schools & College Buses
- Corporate Fleet Operators
AIS 140 GPS Trackers Technical Specifications
| Parameters | Description of ATIL (REVT107-140) |
|---|---|
| Microcontroller | 32 Bit Cortex M3 |
| Chipset | GSM Chipset: MT6261 GNSS & IRNSS Chipset: STA8090 |
| Memory | 4 MB Flash. 100K Erase and Program Cycle 20 Years Data Retention. Expandable upto 8 MB |
| GSM Module | Quad Band GSM 850/900/1800/1900Mhz,DCS GPRS: class10 Coding Scheme CS1 to CS4 |
| GNSS & IRNSS Module | Supports Dual GNSS Bands. L1 and L5 Supports GPS, GLONASS and IRNSS Internal GNSS and IRNSS Antennas <2.5 M CEP @-130d BM |
| Antennae | Internal |
| Communication Interface | TCP, UDP & HTTP |
| Record Storage/buffer | 40000 Tracking Records |
| Ports | 5 Digital Inputs, 2 Analog Inputs, 2 Digital Outputs, 1 SOS Interface One RS232 and Optional CAN |
| Speed Sensor | GNSS |
| SIM Interface | Supports ESIM and Plastic Micro SIM (1.8 & 3.0V) |
| GPRS Packet Data | Class 12, Coding Scheme CS1 to CS4 |
| LED Indication | Main Power, Internal Battery, GSM and GPS |
| Connectors | 16 Pin Connector |
| Power Supply | Wide DC Input Voltage (DC 7 to 40V) |
| Current Consumption | 80 – 100 mA During Transmission. 40 mA During Idle Condition. 20 mA in Sleep Mode |
| Internal Battery | 1000 mA. 6 Hours Backup |
| Enclosure | Nylon FR, Complying to IP67 |
| Temperature | Operating: -25°C to +85°C Storage: -40°C to +85°C |
| Dimension | 102 x 72 x 32 mm |
| Weight | Approximately 200 grams with cable |
| FOTA | Firmware Update Over The Air Over The Air Device Configuration |
| Geo Fencing | Supports Circular and Polygonal Geo Fencing |
| Motion Sensor | 3 Axis Accelerometer and Gyrometer (Harsh Braking and Conering) |
GSM Interference Detection
There is a risk of losing the GPS signal in remote areas, while under the tunnel inside the mountain or due to natural weather patterns. Under such situations, our devices will inform the fleet manager through the GSM network with a frequency band of 900/1800 or 850/1900 Mhz.
Thus, the vehicle will always be visible and there is no chance of misuse or theft of the vehicle greatly enhancing the safety of the passengers or other valuables onboard.
Eco-Friendly
One of the major reasons for environmental pollution and business inefficiency is due to fuel consumption and general wear and tear of the vehicle.
Our route-planning and fuel-monitoring solutions ensure efficient re-planning of routes and leading to greater fuel efficiency and lower maintenance which is beneficial to your company’s balance sheet as well as the environment.
SOS Panic Button
Our REVT107-140 certified GPS devices offer SOS Panic Alert Button which immediately sends alerts, through SMS, Email or registered mobile numbers ensuring the safety and security of the passengers and/or valuables.
This can prove indispensable during crises, when the location information is relayed to the fleet manager every 5 seconds, ensuring that the vehicle is always under supervision.
